ITE External Desktop Power Supplies with C8 Inlets

DoE(VI) / EU ErP & CoC5 Compliance | IEC / UL / EN 62368-1 Safety Approvals

Browse our broad range of external power supply solutions in desktop packages with IEC-320 C8 Inlets for Class I operation. All our desktop power supplies feature Universal AC Input, High Efficiencies and reduced no-load power consumption for DoE(VI) / EU ErP & CoC5 Compliance. Listed below are our standard models, please contact us to discuss any modification and customization requirements you may have.

MOD_SELLACIOUS_FILTERS_FILTER_MOBILE_LABEL

Product	Watts (Convection)	Outputs	V1 Nom	V2 Nom	V3 Nom	Dimensions (mm)	Dimensions (inches)	No Load Power	Efficiency
APSU06B ITE C8 Desktop Power Supplies	6 W	1	3.3~48 V	-	-	80 x 39 x 27.7mm	3.15 x 1.54 x 1.09"	<0.1 W	78.9 %
APSU12B ITE C8 Desktop Power Supplies	12 W	1	3.3~48 V	-	-	80 x 39 x 27.7mm	3.15 x 1.54 x 1.09"	<0.1 W	83.1 %
PA1015D ITE C8 Desktop Power Supplies	15 W	1	3.3~48 V	-	-	80.01 x 39.116 x 26.924	3.15 x 1.54 x 1.06	0.3 W	75 %
GPSU15B ITE C8 Desktop Power Supplies	15 W	1	3.3~48 V	-	-	100 x 58.5 x 32.8mm	3.94 x 2.30 x 1.29"	<0.1 W	84.1 %
APSU15B ITE C8 Desktop Power Supplies	15 W	1	3.3~48 V	-	-	80 x 39 x 27.7mm	3.15 x 1.54 x 1.09"	<0.1 W	84.1 %
GPSU18B ITE C8 Desktop Power Supplies	18 W	1	3.3~48 V	-	-	100 x 58.5 x 32.8mm	3.94 x 2.30 x 1.29"	<0.1 W	85 %
APSU18B ITE C8 Desktop Power Supplies	18 W	1	3.3~48 V	-	-	80 x 39 x 27.7mm	3.15 x 1.54 x 1.09"	<0.1 W	85 %
HEMG26-C8 ITE & Medical C8 Desktop Power Supplies	24 W	1	5~24 V	0	0	110 x 58 x 32.3mm	4.33 x 2.28 x 1.27"	0.1 W	90 %
GPSU25B ITE C8 Desktop Power Supplies	25 W	1	3.3~48 V	-	-	100 x 58.5 x 32.8mm	3.94 x 2.30 x 1.29"	<0.1 W	87 %
APSU25B ITE C8 Desktop Power Supplies	25 W	1	3.3~48 V	-	-	80 x 39 x 27.7mm	3.15 x 1.54 x 1.09"	<0.1 W	87 %
GPSN25B ITE C8 Desktop Power Supplies	25 W	2~3	5~18 V	12~48 V	-5~-18 V	146 x 75.5 x 43mm	5.75 x 2.97 x 1.69"	0.1 W	83.3 %
PA1030T2 ITE C8 Desktop Power Supplies	30 W	1	3.3~48 V	0	0	94.996 x 48.006 x 33.02	3.74 x 1.89 x 1.30	0.3 W	75 %
MPU30B ITE C8 Desktop Power Supplies	30 W	1	3.3~48 V	-	-	107.5 x 67 x 36mm	4.23 x 2.64 x 1.42"	<0.3 W	78 %
GPSU40B ITE C8 Desktop Power Supplies	40 W	1	3.3~48 V	-	-	100 x 58.5 x 32.8mm	3.94 x 2.30 x 1.29"	<0.1 W	87.6 %
PA1045T3A ITE C8 Desktop Power Supplies	45 W	1	12~48 V	0	0	93.98 x 42.926 x 29.972	3.70 x 1.69 x 1.18	0.3 W	86 %
PA1045T3B ITE C8 Desktop Power Supplies	45 W	1	12~48 V	0	0	93.98 x 42.926 x 29.972	3.70 x 1.69 x 1.18	0.3 W	86 %
HEMG56-C8 ITE & Medical C8 Desktop Power Supplies	50 W	1	5~48 V	0	0	110 x 58 x 32.3mm	4.33 x 2.28 x 1.27"	0.1 W	90 %
PA1050T2B ITE C8 Desktop Power Supplies	50 W	1	9~48 V	0	0	109.982 x 54.102 x 30.988	4.33 x 2.13 x 1.22	0.3 W	75 %
PA1060-T2B ITE C8 Desktop Power Supplies	60 W	1	12~48 V	-	-	109.982 x 54.102 x 30.988	4.33 x 2.13 x 1.22	0.3 W	75 %
APSU60B ITE C8 Desktop Power Supplies	60 W	1	5~48 V	-	-	100 x 58.5 x 32.8mm	3.94 x 2.30 x 1.29"	<0.1 W	88 %
PA1065-T2B ITE C8 Desktop Power Supplies	65 W	2	5~48 V	-	-	108.966 x 46.99 x 29.972	4.29 x 1.85 x 1.18	0.3 W	87 %
HEMG76-8 Medical & ITE C8 Desktop Power Supply	75 W	1	48 V	-	-	125 x 61.78 x 32.5	4.92 x 2.43 x 1.28	0.2 W	90 %
PA1090-T2B ITE C8 Desktop Power Supplies	90 W	2	5~48 V	-	-	134.112 x 54.102 x 30.48	5.28 x 2.13 x 1.20	0.3 W	87 %
PA1120-T2B ITE C8 Desktop Power Supplies	120 W	2	5~48 V	-	-	169.926 x 67.056 x 36.068	6.69 x 2.64 x 1.42	0.3 W	87 %
